Technical Data

• Valve function5/2-way, monostable
• Type of actuationElectric
• Construction width52 mm
• Standard nominal flow rate (standardised to DIN 1343)3700 l/min
• pneumatic working portG1/2
• Operating voltageVia solenoid coil, must be ordered separately
• Operating pressure0.2 MPa ... 0.8 MPa
• Operating pressure2 bar ... 8 bar
• DesignPoppet seat
• Type of resetMechanical spring
• Approvalc UL us - Recognized (OL)
• Degree of protectionIP65
• Nominal size14 mm
• Grid dimension69 mm
• Exhaust-air functionWith flow control option
• Sealing principleSoft
